TH2866-AYAKLI

Universal Lathe - With Workbench

With a maximum diameter of 280 millimetres and a maximum length of 660 millimetres, the pedestal universal lathe, which can operate with 220 voltage, allows you to process workpieces precisely. The metal transmission gear and the threading feature are designed for professional work. A wide range of accessories allows you to customise and optimise your work.

ÖZELLIKLER :

Diameter Over Counter 280 mm
660 mm Between Two Tailstocks
Spindle Bore Diameter 26 mm
Main Motor Power 750 W

Ürün Kataloğunu İndir Teknik Özellikleri İncele

TEKNİK

ÖZELLİKLER

	MEASURE VALUE	UNIT OF MEASURE
Diameter Over Counter	280	mm
Over Car Diameter	182	mm
Counter Width	155	mm
Distance Between Centres	660	mm
Spindle Bore Diameter	26	mm
Spindle Speed Number	6
Spindle Speed Range	125-2000	rpm
Main Motor Power	0.75	kW
Car Transverse Movement	170	mm
Car Top Pen Holder Movement	110	mm
Diameter of Tailstock Sleeve	32	mm
Morse Taper of Tailstock Sleeve	MT3
Maximum Travel of Compound Rest	70	mm
Metric Thread Pitches	0,25-3,50	mm
Metric Thread Pitch Units	26
Inch Thread Pitches	8-72	TPI
Inch Thread Pitch Number	36
Car Feed Speed	0.063 - 0.350	mm/min
Machine Dimensions	450x1295x1200	mm
Weight	245	kg

STANDARD

EQUIPMENT

- Spindle Protection Cover

- Toolpost Protection

- Ball Screw Sheet Metal Protection

- Tooth Tracking Eye

STANDARD

ACCESSORIES

- 3 Legged 125 mm Mirror

- 4 Legged 160 mm Shutter Mirror

- Movable Lunet

- Fixed Lunet

- Plate Mirror

- Rotary Tailstock

- Chuck

- Chuck Shank

- Sleeve (MT3-MT2)

- Fixed Tailstock

- Tool Bag

- Tools
